Total Price: $17,995.00
Engine
Engine Type | Kohler, Overhead Valve (OHV) with EFI |
Displacement | 429 cc |
Engine Power | 14.0 hp (10.3 kW) rated @ 3600 RPM per SAE J1940 |
Performance
Top Speed | 19 mph (30 kph) |
Battery
Battery | 12-volt (1) |
Drivetrain
Steering | SportDrive™ — Self-compensating double reduction helical rack & pinion |
Chassis
Chassis | Body and Finish, Front: Painted TPO | Body and Finish, Rear: Painted Surlyn |
Frame Type | AlumiCore™ — Ladder-style aluminum box beam |
Suspension
Front Suspension | Independent A-arms with Hydraulic shocks |
Rear Suspension | Patent pending w/ Track Bar and Automotive Grade Jounce Bumpers |
Brakes
Brake System Type | Self-adjusting, rear wheel mechanical drum |
Parking Brake | Foot actuated, 3-position |
Wheels & Tires
Front Tire | 205 x 55 - 10 Tubeless |
Rear Tire | 205 x 55 - 10 Tubeless |
Dimensions
Dimensions | Front Tread: 36 in | Rear Tread: 40 in |
Overall Vehicle Size (LxWxH) | 108 x 48 3/4 x 71 inches |
Wheelbase | 65 1/2 inches |
Ground Clearance | 4 1/2 inches |
Capacities
Fuel Capacity | 6.0 gal (22.7 L) |
Weights
Weight | Total: 825 lb |
Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
